貼片排容
產品類別：貼片電容
產品簡介：節約空間: 可以節省高達 50%的 PCB 空間位置
服務熱線：0755-8932 5380
產品詳情
片式排容系列(C-ARRAY SERIES)
一、優點 FEATURE
※節約空間: 可以節省高達 50%的 PCB 空間位置， 提高裝配密度
Space saving: CA can save 50% space of the PC board and improve the assembling density. ※更高的體積比容: 安裝一塊 CA 等于安裝 4 塊 0603 片容，減少安裝次數，提高安裝效率
Provide more capacitance per volumetric area: Efficiently use the side margins and thickness. Promoting mounting efficiency. One chip of CA equals to four chips of 0603 type capacitor. So it can reduce times of picking and placing.
※降低成本: 減少放置的次數;縮短生產時間;減少設備管理費用;減少 PCB 費用
Cost saving: Reduce times for picking and placing, reduce manufacturing time, reduce the cost for manage the
equipments and reduce the cost of PCB.
※安裝簡易: 可進行 SMT 編帶包裝，由貼片機高速貼片
Easy to picking and placing: SMT package, easy to mounting.
※提高線路板工作效率: 可以減少印刷的線路。提高線路板的運轉速度，提高工作效率
Improve the working efficiency of the printed board: Reduce the amount of printed circuits and promote the working speed of the printed circuit.
二、用途 APPLICATIONS
※適用于對元器件空間要求嚴格的 PCB，如手提電腦、PDA、無繩電話
Applied in PCB which require strictly about space speed, such as notebook computer, PDA and portable
telephone, etc.
※特別適用于輸入、輸出接口電路
CA is best suitable to use in I/O interface circuit.
